Horse jump wings (wing standards) are the vertical side supports of a show-jumping fence that hold the rails and jump cups. This straight-picket pair is 4 ft tall, 32 in wide, allows a 44 in maximum jumping height, and costs about $56 in materials.
Straight-picket horse jump wings use simple 90-degree cuts on common lumber, which makes this style the easiest wing standard design to build at home. The 4x4 posts, 2x4 crosspieces, 1x4 pickets, and 2x6 feet create a substantial, professional-looking fence similar to show-ring jumps.
What Are Horse Jump Wings?
Horse jump wings, also called wing standards, are tall vertical supports on each side of a jump that hold the jump rails and jump cups. A pair of wings frames the fence, increases its visual presence, and lets you adjust rail height by moving the cups up or down the drilled holes.
- Typical height for schooling wings: about 4 ft with jump cups up to 44 in
- Typical width: about 32 in per wing for a substantial feel
- Main parts: two 4x4 posts, 2x4 crosspieces, 1x4 pickets, and 2x6 feet
- Use: hunter, jumper, and equitation courses in arenas and fields
At a Glance: DIY Straight-Picket Horse Jump Wings
- Design: Straight-picket wing standards with hidden jump cups
- Finished size: 4 ft tall, about 32 in wide, 44 in max jumping height
- Main lumber: 4x4 posts, 2x4 crosspieces, 1x4 pickets, 2x6 feet
- Cut lengths: Posts 48 in; crosspieces 30 in; pickets 40 in; feet 24 in
- Hole spacing: Jump cup holes every 4 in on two posts
- Tools: Circular saw, drill, tape measure, square, driver, sandpaper
- Skill level: Beginner to intermediate DIY with basic power tools
- Approximate cost: $55.70 DIY vs $250+ for a similar ready-made pair
Materials and Tools to Build Wing Standards
This project uses standard dimensional lumber and basic decking screws to build a pair of straight-picket wing standards.
Materials (for one pair of horse jump wings)
- (2) 4 x 4 x 8 ft boards (cut to four 48 in posts)
- (2) 2 x 4 x 8 ft boards (cut to four 30 in crosspieces)
- (6) 1 x 4 x 8 ft boards (cut to fourteen 40 in pickets)
- (1) 2 x 6 x 8 ft board (cut to four 24 in feet)
- 3 in to 3 1/2 in decking screws for attaching feet and posts
- 2 in decking screws for attaching crosspieces and pickets
- Primer paint (if painting)
- Exterior paint or exterior stain
- Jump cups appropriate for 4x4 posts
Tools
- Circular saw or miter saw
- Drill with a bit sized for jump cup hardware holes
- Screwdriver or impact driver
- Tape measure
- Pencil and carpenter’s square
- Sandpaper (around 100-grit) and sanding block or power sander
- Paintbrushes or rollers for paint or stain
Safety note: Wear eye protection, secure lumber on a stable surface while cutting, and keep hands clear of blades and bits.
Cut List for Straight-Picket Horse Jump Wings
This cut list summarizes all lumber dimensions for one pair of wing standards.
| Part | Stock size | Cut length | Quantity |
|---|---|---|---|
| Post | 4 x 4 | 48 in | 4 |
| Crosspiece | 2 x 4 | 30 in | 4 |
| Picket | 1 x 4 | 40 in | 14 |
| Foot | 2 x 6 | 24 in | 4 |
How to Build Horse Jump Wings (Step by Step)
The straight-picket wing is the easiest wing standard style to build, and this sequence shows exactly how to cut, drill, sand, finish, and assemble the pair.
-
Step 1: Cut the 4x4 Posts
Cut four 4x4 posts to 48 in (4 ft) using a circular saw. Mark all four sides of each cut line with a square and pencil so every pass of the saw follows the same line.
Most circular saw blades do not cut through a 4x4 in a single pass, so rotate the board and cut from multiple sides until the cut meets cleanly. Keep the posts equal length so both horse jump wings stand level.
-
Step 2: Drill the Jump-Cup Holes
Mark and drill jump cup holes every 4 in on two of the 4x4 posts to create adjustable rail heights up to about 44 in. Leave the other two posts solid unless jump cups are needed on both sides.
Use a tape measure to mark the hole positions and keep the marks centered on the face of the 4x4 so jump cups sit square. Centering matters most for basic metal cups; premium machined cups tolerate slight variation.
-
Step 3: Cut the 2x4 Crosspieces
Cut four 2x4 crosspieces to 30 in to create wings about 32 in wide. Keep each piece at least 20 in long if a narrower wing is preferred, because wider wings feel more substantial and closer to a true hunter fence.
Place the lower crosspiece just below the first cup hole at 12 in, and locate the upper crosspiece higher on the posts to frame the pickets and support the structure.
-
Step 4: Cut the Pickets and Feet
Cut fourteen 1x4 pickets to 40 in to fill the space between the crosspieces on both wing standards. Keep the picket lengths consistent to maintain an even top line. For matching jump rails, use the same approach described in DIY horse jump poles.
Cut four 2x6 feet to 24 in to create a wide, stable base of support for the tall wings. Use four feet total, two per wing, and do not shorten them, because long feet significantly increase stability.
-
Step 5: Sand and Finish All Parts
Sand all posts, crosspieces, pickets, and feet with about 100-grit sandpaper to remove splinters and smooth the surfaces. Lightly round the exposed top corners of the lumber if a softer, more finished edge is desired.
Apply primer (if painting) and then exterior paint or stain to all sides of every piece before assembly so moisture cannot reach raw wood between boards. Stain gives a classic look, while paint allows color coordination with the rest of the course and can pair with ideas from painting horse jump rails.
-
Step 6: Assemble the Wing Standard Frame
Assemble each wing by attaching two 30 in 2x4 crosspieces between one drilled 4x4 post and one solid 4x4 post. Lay the posts flat, position the crosspieces on top, and use a level to keep everything square and aligned.
Drive 2 in decking screws through each end of the crosspieces into the posts. If a crosspiece covers a drilled cup hole you want to use, re-drill through the 2x4 at that location so the jump cup pin can still pass through.
-
Step 7: Attach the Pickets and Feet
Attach the pickets to the 2x4 crosspieces with 2 in decking screws, spacing them evenly and aligning their edges with the posts so the pickets hide the jump cups from the front. Predrill screw holes at the top and bottom of each picket to prevent the 1x4 boards from splitting.
Attach two 24 in 2x6 feet to the base of each wing, one on each side of the posts, using three 3 in to 3 1/2 in decking screws per foot. Position the feet perpendicular to the face of the wing for maximum lateral stability, following the same principles covered in how to build jump standards.
How Much Does It Cost to Build Horse Jump Wings?
Building this pair of straight-picket horse jump wings costs about $55.70 in materials, which is significantly lower than the $250 or more typically charged for a similar ready-made pair.
- (2) 4 x 4 x 8 ft lumber: $24.00
- (1) 2 x 6 x 8 ft lumber: $7.25
- (2) 2 x 4 x 8 ft lumber: $7.70
- (6) 1 x 4 x 8 ft lumber: $10.80
- Sandpaper: $0.95
- Screws: $5.00
- Stain or paint: on hand, no additional cost in this example
| Option | Approximate cost (per pair) |
|---|---|
| DIY straight-picket horse jump wings | $55.70 in materials |
| Ready-made straight-picket wing standards | $250+ |
The straight-picket wing standard is the easiest and most economical style to build, and small design changes such as angled pickets or different crosspiece lengths can customize the look without changing the basic construction. If building a full practice course, combine these wings with the setup in DIY horse jump set.
Frequently Asked Questions
How much does it cost to build horse jump wings?
Building this pair of straight-picket horse jump wings costs about $55.70 in lumber, screws, and sandpaper, assuming stain or paint is already on hand. Comparable ready-made wing standards typically cost $250 or more per pair, so the DIY option offers significant savings.
How tall should horse jump wings be?
For most home arenas, horse jump wings that are 4 ft tall with jump cups up to about 44 in provide enough height for hunter and lower jumper fences. Taller wings are possible for higher-level courses, but 4 ft wings suit the majority of schooling setups.
What wood do you need for horse jump wings?
You need 4x4 lumber for the posts, 2x4 lumber for the crosspieces, 1x4 lumber for the pickets, and 2x6 lumber for the feet to build these horse jump wings. Standard 8 ft boards in pine or similar softwood work well when sealed with exterior paint or stain.
How far apart should jump cup holes be on wing standards?
Spacing jump cup holes every 4 in on the 4x4 posts gives practical adjustability for hunter and schooling fences. Closer spacing provides more fine-tuned height options, but 4 in increments balance adjustability and drilling time.
What is the easiest horse jump wing style to build?
The straight-picket wing standard is the easiest horse jump wing style to build because it uses only straight cuts and square angles on common lumber sizes. More complex designs with angled pickets or decorative shapes require additional cuts and layout.
